Ranger Rb30T Heavy-Duty Commercial Wheel Balancer — High-Capacity Truck & Bus Model (5140179)

Description

Maximize efficiency in your high-volume shop with the Ranger RB30T Truck Wheel Balancer. Built to handle the heaviest commercial wheels, this professional-grade balancer delivers precision, speed, and operator-friendly features to keep your workflow moving. Ideal for buses, semi-trucks, and fleet maintenance operations.

Features:

• High Capacity Performance: Handles wheels up to 330 lbs and tire diameters up to 49.25-inch with ease.
• Fast, Accurate Balancing: Dynamic, static, and ALU modes with +/- 0.035 oz (1g) car precision and +/- 0.4 oz (12.5g) truck precision.
• Operator-Friendly Design: Pneumatic wheel lift, LED weight indicators, and self-centering quick-chuck adapter for effortless operation.
• Advanced Technology: Drive-Check™ system with 64-bit microprocessor and piezoelectric sensors for high-sensitivity imbalance detection.
• Versatile Adapter Kit Included: Complete multi-piece commercial kit for immediate operation across a wide range of wheels.

Specs:

Power Supply: 220V, 50 / 60 Hz, 1 Ph, 1.5A
Drive Motor: 3 Ph Motor with Solid-State Phase Converter
Operating Temperature: 32 Deg.F – 122 Deg.F (0 Deg.C – 50 Deg.C)
Drive System: Ribbed Nylon Fiber-Reinforced Drive Belt
Cycle Time: 7 seconds (Car) / 20 seconds (Truck)
Balancing Modes: 1 Dynamic / 1 Static / 3 Alloy (ALU1, ALU2, ALUS)
Wheel Spin Braking: Electronic Pulse / Pneumatic Brake
Wheel Hold Device: Pneumatic Brake
Shaft Size: 40 mm
Centering Cones Included: Multi-Piece Commercial Adapter Kit
Max. Tire Diameter: 49.25″ (1,250 mm)
Max. Tire Weight: 330 lbs. (150 kg)
Wheel Diameter Range: 13″ – 24″ (330 mm – 610 mm)
Wheel Width Capacity: 4″ – 20″ (102 mm – 508 mm)
Balancing Increments: 0.035 oz (1 gram)
Balancing Speed: 260 RPM (Car) / 135 RPM (Truck)
Accuracy / Standard: ± 0.035 oz (1 gram)
Accuracy / Truck: ± 0.4 oz (12.5 grams)
Resolution: ± 0.09 oz (2.5 grams)
Shipping Weight: 990 lbs. (449 kg)
