Description
Upgrade your tire shop workflow with the Ranger LS45DS Wheel Balancer. Engineered for high-volume automotive and tire service centers, this semi-automatic balancer combines 3D sonar measurement, Laser-Spot™ weight guidance, and multiple balancing modes to deliver precise, fast, and effortless wheel balancing for rims from 12-inch to 24-inch.
Features:
- 3D Auto Data Entry: Sonar system automatically measures wheel diameter, width, and offset—reduces setup time and errors.
- Laser-Spot™ Guidance: Precisely indicates the correct position for weight placement for faster, accurate balancing.
- Multiple Balancing Modes: Dynamic, static, aluminum (ALU), and hidden weight modes for all wheel types.
- Automatic Braking and Side-Position Hold: Stops the wheel at 12/6 o’clock positions for hands-free weight application.
- High Capacity: Handles wheels up to 145 lbs (≈65 kg), 12-inch–24-inch in diameter, and 4-inch–20-inch width.
- Self-Calibration and User-Friendly: Auto-calibration, open-side hood, and preset workflows for multiple technicians.
- Precision Balancing: Accuracy within +/- 1 g for smooth, safe rides and reduced vibration.
- Optimized Workflow: Quick-release hub nut, no-mar cones, and laser guidance for efficient, professional operation.
Specs:
Motor: 220 VAC, 3A, 50/60 Hz, 1 Ph, 0.55kW
Drive system: Belt Drive
Working temperature: 27 Deg.F – 82 Deg.F (-5 Deg.C – 50 Deg.C)
Operating temperature: 41 Deg.F – 122 Deg.F (5 Deg.C – 50 Deg.C)
Balancing modes: 1 dynamic / 1 static / 3 aluminum alloy / 1 hidden
Maximum tire diameter: 43in (1092 mm)
Maximum wheel weight: 145 lbs. (65 kg)
Max. wheel diameter: 12in – 24in (305 mm – 610 mm)
Wheel width capacity: 4in – 20in (102 mm – 508 mm)
Balancing increments: 0.01 oz (0.25 grams) or 0.25 oz
Accuracy: ± .035 oz (1 gram)
Resolution: .25 oz (5 grams)
Balancing speed: 180 RPM
Top weight locator (12 oftclock): Standard
Bottom weight locator (6 oftclock): Standard
Height, Guard Up: 66in (1,676 mm)
Height, Guard Down: 53in (1,346 mm)
Width: 54in (1,371 mm)
Depth, Cover Up: 39in (990 mm)
Application:
Tire shops & service centers
Automotive repair and maintenance shops
High-volume wheel balancing operations
Passenger cars & light trucks
Alloy and aesthetic-sensitive wheels
Performance & specialty wheels
