Description
Our K45 hub is a precision steel taper-lock weld-on hub designed for 2517 bushings. The compact design of K-25 hubs makes them ideal for conveyor pulleys, end discs, and more! With the precision tolerances used when manufacturing and high-quality steel construction, this K45 hub is easy to weld onto surfaces and allows easy bushing installation and removal. Additionally, our premium K45 hub directly interchanges with other brands and manufacturers. For more information or to get a quote on our K45 hub, contact our customer service team, and we will gladly assist you!
K45 Hub Dimensions
- Hub Size: K45
- Uses Bushing: 4545
- Max. Bushing Bore: 4-15/16″
- Hub Weight: 15.2 LBS
- Dimension (A): 8.50″
- Dimension (B): 2.63″
- Dimension (D): 0.63″
- Dimension (G): 8.000″
- Dimension (J): 6.83″
- Wrench Clerence Req. To Install Bushing (L): 2.63″
- Wrench Clerence Req. To Remove Bushing (M): 4.75″
- Dimension (N): 4.50″
