Description
CSB52MFM205-16 stamped steel bearing is a 2-bolt flush mount flange bearing designed for light-duty industrial and agricultural applications. The superior quality stamped steel housing encases a performance C3 precision 1″ insert bearing that utilizes set screws for securing onto a shaft. CSB52MFM205-16 bearings are more economical than their cast counterparts but offer excellent performance in bearing applications; the two-bolt flange stamped steel housing allows for great mounting when the shaft is positioned perpendicular to the bearing. Utilizing two mounting holes, the CSB52MFM205-16 1″ bearing has incredible holding power, stability, and mounting position flexibility. Additionally, our CSB52MFM205-16 stamped steel bearing features a zinc plated housing for added protection against the elements in corrosive or outdoor applications. For more information or to get a quote on our flush mount CSB52MFM205-16 bearing, contact our customer support team, and we will be happy to assist you!
CSB52MFM205-16 Bearing Dimensions
- Bearing Unit Part #: CSB52MFM205-16
- Bearing I.D.: 1″
- Dimension (a): 3-3/4″
- Dimension (e): 3″
- Dimension (s): 11/32″
- Dimension (b): 2-51/64″
- Dimension (Bi): 1.063″
- Bolt Size: 5/16″
- Insert Bearing #: CSB205-16
- Housing #: 52-2-MFM
- Weight: 0.66 LBS
