Description
Type 4B Heavy Duty 324U Motor Base is designed for applications requiring ease of motor adjustment without loosening motor mounting bolts. Designed for NEMA 324U electric motors, this base will accept any major manufacturer of electric motors. The 4B movable plate adjustable 324U motor base is manufactured using high-strength premium steel for superior durability, rigidity, and overall working life. We also supply a full line of premium electric motors, gear reducers, pulleys, v-belts, roller chains, and sprockets. For more information or to get a quote on an adjustable 324U frame motor base please contact us and we will be happy to assist you!
4B Adjustable 324U Motor Base Dimensions
- Base Size: 33B324
- NEMA Frame 1750 RPM: 324, 324U
- NEMA Frame 1160 RPM: 324, 324U
- Weight: 48 LBS
- Dimension (A): 16-3/8″
- Dimension (B): 14″
- Dimension (C): 11-1/2″
- Dimension (D): 10-1/2″
- Dimension (E): 7-3/4″
- Dimension (F): 5/8″
- Dimension (G): 15-3/4″
- Dimension (H): 4-3/8″
- Dimension (K): 12-1/2″
- Dimension (L): 1-3/4″
- Dimension (M): 5-1/4″
- Dimension (N): 5-1/4″
